How to read Canon projector model names: the REALiS and XEED ranges, resolution, brightness, throw type, light source and DICOM mode.

How to read
REALiS WUX600STZ D
Range
REALiS (USA, Asia) and XEED (Europe) are the very same range under two names: REALiS WUX7000Z = XEED WUX7000Z. Both are professional installation models on LCOS panels with AISYS. LV is the entry-level lamp series.
Resolution
WUX — WUXGA 1920×1200 · SX — SXGA+ 1400×1050 · 4K — 4K DCI 4096×2160. In the LV series: LV-X — XGA · LV-WX — WXGA · LV-HD — Full HD.
Number · brightness
The number = brightness in lumens, unrounded: WUX7000Z → 7,000 lm, WUX5800 → 5,800 lm, WUX450ST → 4,500 lm, 4K600STZ → 6,000 lm, LV-X320 → 3,200 lm.
Throw type
ST — short-throw lens (0.56:1): a large image from close up, with no presenter shadow (WUX500ST, 4K600STZ). Without ST — standard or interchangeable optics.
Light source
Z at the end — laser phosphor: up to 20,000 hours, and up to 40,000 in extended-duration mode (WUX7000Z, 4K600STZ). Lamp models carry no letter of their own — they are all the remaining codes: WUX6700, SX80, LV-X320.
DICOM mode
D at the end — a version with DICOM mode: precise greyscale for X-rays, CT and MRI scans (WUX500ST D, SX6000D). Useful for black-and-white film and photography too.
REALiS WUX600STZ D = a teaching sample with every part of the code · real models combine them differently: XEED 4K600STZ, REALiS WUX500ST D

Information compiled by students

of the Higher Vocational Film College

VPU-K  © 2026

Canon (est. 1937, Tokyo) — 41 consecutive years in the top 10 for US patents granted. It designs and makes its own optics. Its projectors run on a proprietary technology — LCOS panels with the AISYS system, which no one else has. Its 4K6020Z is the world's most compact native 4K laser projector.
